35mm

13mm

1100w

Product Information
Deznet Pro315s magnet drill with the possibility of drilling with a rotary drill up to 35 mm in diameter and a conical or solid drill up to 13 mm in diameter and with a motor power of 1100 watts is known as a powerful and economical device among its peers. This drilling machine supports Weldan 19/05 and has an automatic soapy water oil system. 1100 watt motor power and Pro315s single-speed oil gearbox improve motor efficiency and device life. The speed of this machine is 700 revolutions per minute (RPM) and it is capable of drilling with HSS and TCT drills from 12 to 35 mm in diameter, as well as drilling with conical and round drills up to 13 mm in diameter (using three systems). . It should be noted that this magnetic drill machine has high precision and body quality and is protected against overload, so that if too much pressure is applied to the machine, its motor will turn off automatically. This device comes standard with a 55 mm cutting depth holder, so if you need a cutting depth of up to 110 mm, you can use two-piece pins.
TITLE |
DESCRIPTION |
---|---|
Rotation Direction |
clockwise |
Type of Gear box lubrication |
oil |
Magnetic Adhesion |
1000 kg |
Magnetic Foot |
fixed |
Weight |
11.00 kg |
Application |
drilling, countersinking |
TITLE |
DESCRIPTION |
---|---|
Diameter range of annular cutters (HSS & TCT) |
12-35 mm |
Diameter range of countersinking |
10-30 mm |
Diameter range of twist drills |
3-13 mm |
Arbor |
❌ |
Chuck |
✔️ |
TITLE |
DESCRIPTION |
---|---|
Stroke |
210 mm |
Magnet size |
167mm x 84mm x 44mm |
Overall Height |
400-615 mm |
Overall Length |
275 mm |
TITLE |
DESCRIPTION |
---|---|
Motor Power |
1100 w |
Total Power |
- |
Tension Voltage |
110-230 v |
Power Supply Type |
- |
TITLE |
DESCRIPTION |
---|---|
Speed Gear |
700 RPM |
Overheating Protection |
✔️ |
Premanent Internal Lubrication |
✔️ |
Magnetic Indictor |
✔️ |
Torque Control |
✔️ |
